King Guard 3000 Baggage Scanner

Previous Product | Next Product
Product Description


General Specifications:
Tunnel Size : 530(W)×350(H)mm
Conveyor Speed: 0.22m/s
Conveyor Max Load: 150 kg
Single inspection dosage: <1.01μGy
Leakage radiation: <0.06μGy/h
Wire Resolution: 40AWG
Steel Penetration: 43mm
Film Safety: For ISO 1600

X-RAY GENERATOR
Orientation: Upward
Tube Current: 0.2-1.25mA(adjustable)
Anode Voltage: 80-160KV(adjustable)
Angle: 80°

Generator cooling/working periods:
Sealed oil bath with forced air/100%

OPERATING ENVIRONMENT

Storage Temperature: -20oC to 60oC
Operating Temperature: 0oC to 45oC
Relative Humidity:20 to 95% non-condensing
System Power: 220 VAC (±10%) 50±3HZ
Power wastage: 1.0 KW (Max)
Noise<55DB
X-RAY Sensor: L-shaped array detector, 24bit

Image Performance System:
 Display: High-resolution 19 inch color LCD display
 Color quality: 24-Bit real colors based on materials
 Edge enhancement: Object contour edge is more distinct
 Super image enhancement: Image detail is more distinct
 High penetration display: Increase the contrast of bright area in image to make the area that is easy to penetrate appear more clearly
 Low penetration display: Increase the contrast of dark area in image to make the area that is difficult to penetrate appear more clearly.
 Magnifier: Partial magnifying function
 Brightening/dimming: Increase/Decrease brightness of image
 Image recurrence: Display the previous twenty images and process any one of them
 Image restoration: Restore image to initial status
 Image storage: Real-time store any image and process it in operation status
 Multi-energy: High/low energy: Switch from high energy to low energy
 Color material identification: Organic objects in orange, inorganic objects in blue, mixture in green

Assist to detect drug and explosive powder

Special features:

Network interface: Capable of connecting to LAN, and support multi-terminal check for baggage at same time
Safety ray: Ray is transmitted under automatic control, avoiding the error
One-key shutdown control: Just rotate the key to shut down the machine; it is safety, easy and convenient
Eagle eye: Capable of expediently observing the magnifying area
Self-diagnosis function: Give message automatically if malfunction for prompt maintenance
